This enclosed aluminum car trailer is ready for your next track day no matter where that may take you. Designed for better fuel efficiency with a lower deck height and a sharp 52″ V-nose to cut through the wind this trailer will effortlessly follow you, much like your competition!
The rear ramp door height comes in at 72″ high (for a 6’6″ interior) and can be increased with optional beavertail to decrease the grade for those low profile cars! Our car hauler trailers come standard with great features like a side access door, pop-up roof vent, LED trailer lights, multiple interior lights, white FRP finished interior walls, self-adjusting 10″ electric brakes on both axles, and Dexter Torflex 3.5k drop axles. Even the 4 in-floor D-rings have backing plates welded to the frame! Lighter weight aluminum trailers mean you get more payload capacity out of the 7k GVWR compared to steel trailers and you’ll save a ton on gas! Craving even more payload? Check out our 9.9k GVWR Series!
Swipe To See More Images
| Model | CRHL 818LB | CRHL 820LB | CRHL 822LB |
|---|---|---|---|
| Factory Direct Price 6'6" Max Int Ht | $14,095 | $14,795 | $15,595 |
| Interior Length | 17' 11" Box + 52" V | 19' 11" Box + 52" V | 21' 11" Box + 52" V |
| Interior Width | 96" | ||
| Interior Height | 5'6", 6'1", 6'6", or 7'0" Options, Net Height Is Less | ||
| Overall Length | 25' | 27' | 29' |
| Overall Width | 102" | ||
| Overall Height | 105" (6'6" Max Interior Height) | ||
| Deck Height | 21" | ||
| Top of Ball / Ball Size | 17" / 2-5/16" | ||
| Curb Weight* | 2500# | 2700# | 2850# |
| GVWR | 7000# | ||
| Model | CRHL 816LB | CRHL 818LB | CRHL 820LB | CRHL 822LB |
|---|---|---|---|---|
| Frame | All Aluminum Tubular - Heavy Duty 2"x5" Main Frame 16" On Center Floor Crossmembers |
|||
| Axles | (2) 3.5k Galvanized Dexter Torflex™ w/ EZ Lube Hubs | |||
| Brakes | 10" Electric Self Adjusting on Both Axles | |||
| Tires | 15" Radial Tires | |||
| Wheels | Galvanized Wheels w/ Chrome Center Caps & Acorn Lug Nuts | |||
| Distance Between Wheel Wells | 83-1/2" | |||
| Wheel Well Height | 11" | |||
| Exterior Skin | .030 Painted Aluminum - Screwless 24" Stoneguard on V-Nose |
|||
| Wall/Roof Structure | All Aluminum Tubular - 16" On Center | |||
| Roof Skin | Seamless Mill Finish Aluminum | |||
| Flooring | 3/4" GP DryMax High Performance Floor | |||
| Exterior Lights | All LED (Stop-Turn-Tail, Side Marker, Clearance, Plate Light) |
|||
| Interior Lights | 3 (LED) | 4 (LED) | 5 (LED) | |
| Interior | White FRP Finished Interior Walls | |||
| Tiedowns | Four D-Rings with Aluminum Backing Plates | |||
| Trailer Doors | 90" Wide Heavy Duty Rear Ramp Door w/ Spring Assist 32" x 68" Side Access Door w/ RV Lock |
|||
| Ramp Door Hinges | Aluminum w/ Grease Fittings | |||
| Jackstand | Pedestal Mount Jackstand w/ Removable Foot | |||
| Ventilation | CHOICE: Ventline Pop-Up Roof Vent (1) or Black Plastic Sidewall Vents (2) |
|||
| 12 V Power | 7 Way Round | |||
Every PROLine trailer is available in multiple different solid colors at no additional charge for any one color. We also offer Blackout Trim, Two-Tone combinations, Two-Tone w/ ATP Accent, & Aluminum Stoneguard Sides. |
||
 |  | ![trailer color](https://nhtrailers.com/wp-content/uploads/2023/06/TrailerColor-Silver.jpg") |
 |  |  |
 |  |  |
 |  | |
SKU-STS15
Add to cart
Our aluminum trailers are built to last, starting with rugged main tubes and fully welded joints. We know what types of roads our trailers are dragged over when they leave our facility and our trailers are ready for them.
A strong frame is only as good as the components to support it. This is why we use only the best of parts on our aluminum trailers like galvanized Dexter torsion axles, high quality radial tires, LED lighting, and self-adjusting brakes.
Our roofs are built with rugged 1″×2″ aluminum tubes on 16″ centers. That means a roof nearly 2.5 times stronger than many other trailers on the market. We tend to get a lot of snow in New Hampshire, our trailers are ready for it.
Every trailer we build is checked and double checked before it leaves our shop. We want to make sure our trailers are looking their best with screws lining up, lines cut straight, doors installed tight, and every trim screw properly located.
