NEW for the 2024 model year are our V101 Series snowmobile trailers! These are a full 101″ width, deckover style trailer, with a beautiful 36″ V-nose. A comfortable mix between the hybrid and V-nose with front ramp. The V-Nose design not only adds style but also enhances aerodynamics for better fuel efficiency. It offers extra storage space for gear and equipment.
Standard on all of our trailers are galvanized Dexter torsion axles that will provide you with a long lasting and smooth ride. These axles are mounted to a rugged 2″x5″ tubular aluminum main frame to give the strength you need for many years to come. Wall and ceiling supports are on 16″ centers to handle snow load for the harsh New England winters.
In addition to strength, these V front snowmobile trailers come with lots of amenities such as LED lighting, including multiple LED interior lights, RV style side door with continuous hinge, ventilation options, adjustable tie down rails that are welded directly to the frame, and dependable spring assisted rear ramp door.
| Model | V101-12 | V101-14 | V101-16 | V101-20 | V101-22 |
|---|---|---|---|---|---|
| Factory Direct Price 6'1" Max Int Ht | $6,995 | $7,395 | $9,895 | $11,695 | $12,395 |
| Factory Direct Price 6'6" Max Int Ht | $7,075 | $7,705 | $10,735 | $11,995 | $12,725 |
| Interior Length | 11'11" + 36" V | 13'11" + 36" V | 15'11" + 36" V | 19'11" + 36" V | 21'11" + 36" V |
| Interior Width | 98-1/4" | ||||
| Interior Height | 5'6"-6'6" Max Ht Options | 5'6"-7'0" Max Ht Options | |||
| Overall Length | 17'9" | 19'9" | 21'9" | 25'9" | 27'9" |
| Overall Width | 102" | ||||
| Overall Height | See Link | ||||
| Deck Height | 25" | 29" | |||
| Top of Ball / Ball Size | 21" / 2" | 25" / 2" | |||
| Curb Weight* | 1325# | 1480# | 1875# | 2150# | 2275# |
| GVWR | 2990# | 6000# | 7000# | ||
| Note | Other sizes available. Call for details. | ||||
| Model | V101-12 | V101-14 | V101-16 | V101-20 | V101-22 |
|---|---|---|---|---|---|
| Frame | All Aluminum Tubular - 2"x5" Main Frame | Heavy Duty 2" x 5" | |||
| Axles | Galvanized Dexter Torflex w/ EZ Lube Hubs | ||||
| Axle Qty | One (3.5k) | One (3.5k) | Two (3.5k) | Two (3.5k) | Two (3.5k) |
| Brakes | Optional | Optional | 10" Electric Both Axles | ||
| Tires | 10" Radial (ST205/65R10 LRE) | 12" Radial (ST145/R12 LRE) | 13" Radial (ST175/80R13 LRD) | ||
| 6 Year Tire Warranty w/ 2 Years of Roadside Assistance | |||||
| Wheels | Galvanized Wheels | ||||
| Exterior Skin | .030 Painted Aluminum Sheets - Screwless 24" Stoneguard on V |
||||
| Wall/Roof Structure | All Aluminum Tubular - 16" On Center | ||||
| Roof Skin | Seamless Mill Finish Aluminum | ||||
| Flooring | 3/4" GP DryMax High Performance Floor | ||||
| Exterior Lights | LED Stop-Turn-Tail, LED Side Marker, LED Clearance, LED Plate Light | ||||
| Interior Lights | 2 | 2 | 3 | 4 | 4 |
| Interior | 12" Kickboard | ||||
| Tiedowns | 2 Quick-Adjust Floor Rails w/ Ski Tie Down Bars | ||||
| Trailer Doors | Rear Ramp Door w/ Spring Assist & Snow-Flap 32" Side Access Door w/ RV Lock |
||||
| Jackstand | Swivel Jackstand w/ Wheel | ||||
| Ramp Door Opening | 93" Wide | ||||
| Ramp Door Hinges | Aluminum w/ Grease Fittings | ||||
| Ventilation | CHOICE: Ventline Pop-Up Roof Vent (1) or Black Plastic Sidewall Vents (2) | ||||
| 12V Power | 4 Way | 4 Way | 7 Way (CW) | 7 Way (CW) | 7 Way (CW) |
Every PROLine trailer is available in multiple different solid colors at no additional charge for any one color. We also offer Blackout Trim, Two-Tone combinations, Two-Tone w/ ATP Accent, & Aluminum Stoneguard Sides. |
||
 |  | ![trailer color](https://nhtrailers.com/wp-content/uploads/2023/06/TrailerColor-Silver.jpg") |
 |  |  |
 |  |  |
 |  | |
SKU-Canopy
Add to cart
SKU-STS10R
Add to cart
SKU-TWM
Add to cart
SKU-110V-Simple
Select options This product has multiple variants. The options may be chosen on the product page
SKU-QADR
Add to cart
SKU-RoofRake-BigRig16
Add to cart
SKU-PURV-RVCover
Add to cart
SKU-LK-Pucklock
Select options This product has multiple variants. The options may be chosen on the product pageOur aluminum trailers are built to last, starting with rugged main tubes and fully welded joints. We know what types of roads our trailers are dragged over when they leave our facility and our trailers are ready for them.
A strong frame is only as good as the components to support it. This is why we use only the best of parts on our aluminum trailers like galvanized Dexter torsion axles, high quality radial tires, LED lighting, and self-adjusting brakes.
Our roofs are built with rugged 1″×2″ aluminum tubes on 16″ centers. That means a roof nearly 2.5 times stronger than many other trailers on the market. We tend to get a lot of snow in New Hampshire, our trailers are ready for it.
Every trailer we build is checked and double checked before it leaves our shop. We want to make sure our trailers are looking their best with screws lining up, lines cut straight, doors installed tight, and every trim screw properly located.
