As with any trailer we build, quality parts and ingenuity are found throughout. Starting off on what touches the ground, we utilize a quality 15″ radial tire that carries a 5 year warranty. And you won’t have to worry about your motorcycle getting jostled around too much, Dexter torsion axles will help dampen some of the bumps and are standard on every PROLine trailer. If you end up finding some potholes, and we know you will, you won’t have to worry too much. Our fully adjustable Quick Adjust Floor Rail System provides you infinite adjustability on securement points for tying down your bike. So go ahead, pick out your wheel chock, and finally check that trip to Sturgis or Daytona off your motorcycle bucket list!
| Model | MOT 610 | MOT 612 |
|---|---|---|
| Factory Direct Price 6'1" Max Int Ht | $6,895 | $7,495 |
| Interior Length | 9'11" box + 3' V-nose | 11'11" box + 3' V-nose |
| Interior Width | 69" | |
| Interior Height | 5'6", 6'1", or 6'6" Options, Net Height Is Less | |
| Overall Length | 15'1" | 17'1" |
| Overall Width | 94" | |
| Overall Height | 96" (6'1" Max Interior Height) | |
| Deck Height | 18" | |
| Top of Ball / Ball Size | 17" / 2" | |
| Curb Weight* | 1100# | 1200# |
| GVWR | 2990# | |
| Note | Other sizes available. Call for details. | |
| Model | ALL MODELS |
|---|---|
| Frame | All Aluminum Tubular - 2"x5" Main Frame |
| Axles | 3.5k Galvanized Dexter Torflex™ w/ EZ Lube Hubs |
| Brakes | Option |
| Tires | 15" Radial Tires (ST205/75R15 LRC) |
| Wheels | Galvanized Wheels w/ Chrome Center Caps & Acorn Lug Nuts |
| Exterior Skin | .030" Painted Aluminum - Screwless 24" Stoneguard on V-Nose |
| Wall/Roof Structure | All Aluminum Tubular - 16" On Center |
| Roof Skin | Seamless Mill Finish Aluminum |
| Flooring | 3/4" GP DryMax High Performance Floor |
| Exterior Lights | All LED (Stop-Turn-Tail, Side Marker, Clearance, Plate Light) |
| Interior Lights | 2 |
| Interior | White FRP Finished Interior Walls |
| Tiedowns | 3 Quick-Adjust Floor Rails |
| Trailer Doors | 64" Wide Rear Ramp Door w/ Spring Assist & Transition Flap 32" x 68" Side Access Door w/ RV Lock |
| Ramp Door Hinges | Aluminum w/ Grease Fittings |
| Jackstand | Swivel Jackstand w/ Wheel |
| Ventilation | CHOICE: Ventline Pop-Up Roof Vent (1) or Black Plastic Sidewall Vents (2) |
| 12 V Power | 4 Way |
Every PROLine trailer is available in multiple different solid colors at no additional charge for any one color. We also offer Blackout Trim, Two-Tone combinations, Two-Tone w/ ATP Accent, & Aluminum Stoneguard Sides. |
||
 |  | ![trailer color](https://nhtrailers.com/wp-content/uploads/2023/06/TrailerColor-Silver.jpg") |
 |  |  |
 |  |  |
 |  | |
SKU-STS15
Add to cart
SKU-TWM
Add to cart
SKU-AWUG15
Select options This product has multiple variants. The options may be chosen on the product page
SKU-110V-Simple
Select options This product has multiple variants. The options may be chosen on the product page
SKU-QADR
Add to cart
SKU-LED-IntAdd
Add to cart
SKU-SDRV
Select options This product has multiple variants. The options may be chosen on the product page
SKU-LT-SwitchDimmer
Add to cart
SKU-LED-Ghost-
Select options This product has multiple variants. The options may be chosen on the product page
SKU-LED-BULit
Add to cart
SKU-LED-Loading
Add to cart
SKU-CHX-
Select options This product has multiple variants. The options may be chosen on the product page
SKU-FLRQuad
Read more
SKU-QAEB
Add to cart
SKU-PURV-RVCover
Add to cart
SKU-BENCH-12x21
Add to cart
SKU-LK-Pucklock
Select options This product has multiple variants. The options may be chosen on the product page
SKU-FINCEILING
Read moreOur aluminum trailers are built to last, starting with rugged main tubes and fully welded joints. We know what types of roads our trailers are dragged over when they leave our facility and our trailers are ready for them.
A strong frame is only as good as the components to support it. This is why we use only the best of parts on our aluminum trailers like galvanized Dexter torsion axles, high quality radial tires, LED lighting, and self-adjusting brakes.
Our roofs are built with rugged 1″×2″ aluminum tubes on 16″ centers. That means a roof nearly 2.5 times stronger than many other trailers on the market. We tend to get a lot of snow in New Hampshire, our trailers are ready for it.
Every trailer we build is checked and double checked before it leaves our shop. We want to make sure our trailers are looking their best with screws lining up, lines cut straight, doors installed tight, and every trim screw properly located.
