Trailer Highlights
All Aluminum Framing
Heavy Duty Construction
Fully Welded Frames
Triple Tube Tongue
Screwless Exterior Panels
Galvanized Torsion Axles
3/4″ DryMax Flooring
Dozens of Available Options
These enclosed aluminum cargo trailers carry many names due to their versatility but are customizable to work how you need them to. Available with your choice of rear ramp door with spring assist or rear cargo doors at no cost difference. These trailers are 8′ wide on the inside to allow for plenty of room for your mowers, tools, or shelving. 8′ wide aluminum trailers are a great alternative to expensive box trucks that rust out after a few short years.
Our trailers are built on fully welded all aluminum tubular frames making them incredibly rugged yet still lightweight. Let us design one that will meet your business’ needs. The 8′ Wide Series is great when you need extra room for your mobile workshop!
We know your trailer needs to be versatile which is why we offer dozens of options. To further customize your trailer we even have a variety of 110 Volt Packages to make your trailer start working for you! All this with the same great standard features you’d expect from PROLine: side access door, choice of rear ramp door or cargo doors, aluminum stoneguard on the front, all LED lights, multiple interior lights, tongue jack, and rugged 3/8″ finished interior walls are just some of the standard features on our all aluminum construction trailers.
Make your next trailer your last! No rust, long lasting aluminum.
Pricing & Specs
Model | CON 814 | CON 816 | CON 818 | CON 820 |
---|---|---|---|---|
Factory Direct Price 6'6" Max Int Ht | $11,695 | $12,195 | $12,995 | $13,595 |
Interior Length | 13'11" | 15'11" | 17'11" | 19'11" |
Interior Width | 95.5" | |||
Interior Height | 5'6", 6'1", 6'6", 7', or 7'6" Options, Net Height Is Less | |||
Overall Length | 18'10" | 20'10" | 22'10" | 24'10" |
Overall Width | 8'6" | |||
Overall Height | 100" (6'6" Max Interior Height) | |||
Deck Height | 21" | |||
Top of Ball / Ball Size | 17" / 2-5/16" | |||
Curb Weight* | 2300# | 2400# | 2500# | 2600# |
GVWR | 7000# |
Standard Features
Model | CON 814 | CON 816 | CON 818 | CON 820 |
---|---|---|---|---|
Frame | All Aluminum Tubular - Heavy Duty 2"x5" Main Frame | |||
Axles | 3500# Dexter Torflex w/ EZ Lube Hubs | |||
Brakes | 10" Electric Self Adjusting on Both Axles | |||
Tires/Wheels | 15" Radial Tires on Galvanized Wheels | |||
Exterior Skin | .030 Painted Aluminum Sheets - Screwless Stoneguard on Trailer Front |
|||
Wall/Roof Structure | All Aluminum Tubular - 16" On Center | |||
Roof Skin | Seamless Mill Finish Aluminum | |||
Flooring | 3/4" GP DryMax High Performance Floor | |||
Exterior Lights | LED Stop-Turn-Tail, LED Side Marker, LED Clearance, LED Plate Light | |||
Interior Lights | 3 | 4 | 4 | 5 |
Interior | 3/8" GP Drymax Finished Interior Walls | |||
Tiedowns / Roof Racks | Option | |||
Trailer Doors | 32" x 68" Side Access Door w/ RV Lock CHOICE: Rear Ramp Door w/ Spring Assist or Rear Cargo Doors |
|||
Distance Between Wheel Wells | 83.5" | |||
Jackstand | Pedestal Mount Jackstand w/ Removable Foot | |||
Ventilation | Option | |||
12 V Power | 7 Way (CW) |
Available Colors
Every PROLine trailer is available in multiple different solid colors at no additional charge for any one color. We also offer Two-Tone combinations, Two-Tone w/ ATP Accent, & Aluminum Stoneguard Sides. |
||||
![]() White | ![]() Black | ![]() Silver | ![]() Pewter Metallic | ![]() Charcoal Metallic |
![]() Red | ![]() Orange | ![]() Blue | ![]() Yellow | ![]() Two-Tone +$300 |
Get A Custom Quote
Call us at 603-652-7337 or e-mail us to discuss the best trailer for your needs. We’d be happy to discuss our many different trailer models, options, and accessories to find the configuration that’s right for you. Once we know what you’re looking for we can put together a custom, itemized quote for you to review.
-
Spare Tire – 15″ on Galvanized Wheel
$195.00 -
Trailer Spare Tire Wall Mount
$95.00 -
Upgrade to Aluminum Wheels – 15″
$75.00 -
110V 30Amp Packages
$700.00 -
12V Battery w/ 110V Charge Kit
$445.00 – $610.00 -
Add’l LED Interior Lights
$25.00 -
Aluminum Sidewall Vent
$75.00 -
E-Track
-
LED Backup Lights
$120.00 -
LED Loading Lights
$90.00 -
Stabilizer Jacks – 5k# Rating
$250.00 -
Stabilizer Jacks – Drop Leg
$265.00
