Looking for a rugged all aluminum construction trailer to improve the efficiency of your business? Our 9.9k GVWR aluminum construction trailers are built to take the abuse of your crew for years to come. We start with proprietary, heavy walled, 2″x6″ all aluminum tubular framing and tongue tubes. These main carrying beams run the full length of the trailer with floor cross members on 16″ centers. The A-frame style tongue is comprised of three more of the same heavy duty aluminum tubes and runs several feet into the trailer box to properly distribute stresses as you make it from one job site to the next. An aluminum construction trailer from PROLine Products means it can be customized with dozens of options so you can equip your trailer with the features and tools you need to be as efficient and successful as possible. Saving a few minutes each day will make the trailer pay for itself in a short period of time.
Swipe To See More Images
| Model | CON 814 HD | CON 816 HD | CON 818 HD | CON 820 HD |
|---|---|---|---|---|
| Factory Direct Price 6'6" Max Int Ht | $12,795 | $13,395 | $14,095 | $14,895 |
| Interior Length | 13'11" Box | 15'11" Box | 17'11" Box | 19'11" Box |
| Interior Width | 96" | |||
| Interior Height | 5'6", 6'1", 6'6", or 7'0" Options, Net Height Is Less | |||
| Overall Length | 18'10" | 20'10" | 22'10" | 24'10" |
| Overall Width | 102" | |||
| Overall Height | 102" (6'6" Max Interior Height) | |||
| Deck Height | 22-1/2" | |||
| Top of Ball / Ball Size | 19" / 2-5/16" | |||
| Curb Weight* | 2450# | 2550# | 2675# | 2850# |
| GVWR | 9900# | |||
| Note | Other widths and lengths available. Call for details. | |||
| Model | CON 814 HD | CON 816 HD | CON 818 HD | CON 820 HD |
|---|---|---|---|---|
| Frame | All Aluminum Tubular - Heavy Duty 2"x6" Main Frame | |||
| Axles | Two 5200# Dexter Torflex w/ EZ Lube Hubs | |||
| Brakes | 12" Electric Self Adjusting on Both Axles | |||
| Tires/Wheels | 15" Radial Tires on 6 Lug Galvanized Wheels | |||
| Exterior Skin | .030 Painted Aluminum Sheets - Screwless Stoneguard on Trailer Front |
|||
| Wall/Roof Structure | All Aluminum Tubular - 16" On Center | |||
| Roof Skin | Seamless Mill Finish Aluminum | |||
| Flooring | 3/4" GP DryMax High Performance Floor | |||
| Exterior Lights | LED Stop-Turn-Tail, LED Side Marker, LED Clearance, LED Plate Light | |||
| Interior Lights | 3 | 4 | 4 | 5 |
| Interior | 3/8" GP Drymax Finished Interior Walls | |||
| Tiedowns / Roof Racks | Option | |||
| Trailer Doors | 32" x 68" Side Access Door w/ RV Lock CHOICE: Rear Ramp Door w/ Spring Assist or Rear Cargo Doors |
|||
| Distance Between Wheel Wells | 78" | |||
| Jackstand | Pedestal Mount Jackstand w/ Removable Foot | |||
| Ventilation | Option | |||
| 12 V Power | 7 Way (CW) | |||
Every PROLine trailer is available in multiple different solid colors at no additional charge for any one color. We also offer Blackout Trim, Two-Tone combinations, Two-Tone w/ ATP Accent, & Aluminum Stoneguard Sides. |
||
 |  | ![trailer color](https://nhtrailers.com/wp-content/uploads/2023/06/TrailerColor-Silver.jpg") |
 |  |  |
 |  |  |
 |  | |
SKU-LRR
Select options This product has multiple variants. The options may be chosen on the product page
SKU-FLU
Add to cart
SKU-STS156D
Add to cart
SKU-TWM
Add to cart
SKU-HRUG
Read more
SKU-BRLK
Add to cart
SKU-ETRK
Read more
SKU-SkidWheels-BoltOn
Add to cart
SKU-LED-Ghost-
Select options This product has multiple variants. The options may be chosen on the product page
SKU-LTRK-
Select options This product has multiple variants. The options may be chosen on the product page
SKU-LED-BULit
Add to cart
SKU-TD-RackStrap
Add to cart
SKU-STP-RD
Add to cart
Our aluminum trailers are built to last, starting with rugged main tubes and fully welded joints. We know what types of roads our trailers are dragged over when they leave our facility and our trailers are ready for them.
A strong frame is only as good as the components to support it. This is why we use only the best of parts on our aluminum trailers like galvanized Dexter torsion axles, high quality radial tires, LED lighting, and self-adjusting brakes.
Our roofs are built with rugged 1″×2″ aluminum tubes on 16″ centers. That means a roof nearly 2.5 times stronger than many other trailers on the market. We tend to get a lot of snow in New Hampshire, our trailers are ready for it.
Every trailer we build is checked and double checked before it leaves our shop. We want to make sure our trailers are looking their best with screws lining up, lines cut straight, doors installed tight, and every trim screw properly located.
