Trailer Highlights
Sturdy All Aluminum Frame
Adjustable Tie Down System
Dexter Torsion Axles
Galvanized Axles & Wheels
15″ Radial Tires
All LED Lighting
White Finished Interior Walls
Customizable For Your Needs
PROLine’s 7.5′ wide motorcycle trailers are some of the most versatile trailers on the market. Designed from the ground up for hauling motorcycles the 90″ interior width gives you room to fit two motorcycles side by side. Also, the low deck height improves the trailer’s aerodynamics and center of gravity but also allows for an easier ramp angle to get your bikes loaded into the trailer.
Five rows of fully adjustable tie-down rails welded to the trailer frame accommodate a combination of multiple bikes, trikes, Can Am Spyders, and whatever other gear you may have. With our tie down rail system, you’re not forced into putting your bikes in the same spot each time allowing you to maximize floor space in the trailer and making it easier to maintain a balanced load.
Structurally this trailer is designed with a very rigid all aluminum frame mated to a pair of Dexter Torflex Axles. The rubber torsion axles give your bikes a much smoother ride compared to spring axles. On those axles, you’ll find 15″ radial tires that carry a 5 year warranty and 10″ self-adjusting brakes for all 4 wheels. A 3/4″ flooring is used on all of our enclosed trailers so the weight of your bike is properly supported on the frame. Overhead you’ll find 2″ thick roof cross members on 16″ centers so not only will your trailer be ready for your motorcycles in the summer months but will hold up just fine as the snow piles on over the course of winter.
Consider adding our 110V package to trickle charge your bike batteries for long term storage as well.
These enclosed motorcycle hauler trailers are great for a variety of bikes or even trikes or Can Am Spyder! As always, if you have a unique motorcycle or situation feel free to give us a call. With years of trailer experience, our friendly sales staff can help design a trailer to accommodate most anything on two (or three) wheels.
Pricing & Specs
Model | MOT 90-12 | MOT 90-14 | MOT 90-16 | MOT 90-18 | MOT 90-20 |
---|---|---|---|---|---|
Factory Direct Price 6'1" Max Int Ht | $11,195 | $11,895 | $12,595 | $13,595 | $14,295 |
Interior Length | 11'11" box + 52" V | 13'11" box + 52" V | 15'11" box + 52" V | 17'11" box + 52" V | 19'11" box + 52" V |
Interior Width | 7-1/2' (90") | ||||
Interior Height | 5'6", 6'1", 6'6", or 7'0" Options, Net Height Is Less | ||||
Overall Length | 18'9" | 20'9" | 22'9" | 24'9" | 26'9" |
Overall Width | 102" | ||||
Overall Height | 99" (6'1" Max Interior Height) | ||||
Deck Height | 21" | ||||
Top of Ball / Ball Size | 17" / 2-5/16" | ||||
Curb Weight* | 2025# | 2100# | 2200# | 2300# | 2400# |
GVWR | 7000# |
Standard Features
Model | MOT 90-12 | MOT 90-14 | MOT 90-16 | MOT 90-18 | MOT 90-20 |
---|---|---|---|---|---|
Frame | All Aluminum Tubular - 2"x5" HD Main Frame | ||||
Axles | (2) 3.5k Galvanized Dexter Torflex™ w/ EZ Lube Hubs | ||||
Brakes | 10" Electric Self Adjusting on Both Axles | ||||
Tires | 15" Radial Tires (ST205/75R15 LRC) | 15" Radial Tires (ST205/75R15 LRD) | |||
Wheels | Galvanized Wheels w/ Chrome Center Caps & Acorn Lug Nuts | ||||
Exterior Skin | .030 Painted Aluminum - Screwless 24" Stoneguard on V-Nose |
||||
Wall/Roof Structure | All Aluminum Tubular - 16" On Center | ||||
Roof Skin | Seamless Mill Finish Aluminum | ||||
Flooring | 3/4" GP DryMax High Performance Floor | ||||
Exterior Lights | All LED (Stop-Turn-Tail, Side Marker, Clearance, Plate Light) | ||||
Interior Lights | 2 | 3 | 3 | 4 | 4 |
Interior | White FRP Finished Interior Walls | ||||
Tiedowns | 5 Quick-Adjust Floor Rails | ||||
Trailer Doors | 85" Wide Rear Ramp Door w/ Spring Assist & Transition Flap 32" x 68" Side Access Door w/ RV Lock |
||||
Ramp Door Hinges | Aluminum w/ Grease Fittings | ||||
Jackstand | Pedestal Mount Jackstand w/ Removable Foot | ||||
Ventilation | Ventline Pop-Up Roof Vent | ||||
12V Power | 7 Way |
Available Colors
Every PROLine trailer is available in multiple different solid colors at no additional charge for any one color. We also offer Two-Tone combinations, Two-Tone w/ ATP Accent, & Aluminum Stoneguard Sides. |
||||
![]() White | ![]() Black | ![]() Silver | ![]() Pewter Metallic | ![]() Charcoal Metallic |
![]() Red | ![]() Orange | ![]() Blue | ![]() Yellow | ![]() Two-Tone +$300 |
Get A Custom Quote
Call us at 603-652-7337 or e-mail us to discuss the best aluminum motorcycle trailer for your needs. We’d be happy to discuss our many different trailer models, options, and accessories to find the configuration that’s right for you. Once we know what you’re looking for we can put together a custom, itemized quote for you to review.
-
Spare Tire – 15″ on Galvanized Wheel
$195.00 -
Trailer Spare Tire Wall Mount
$95.00 -
Upgrade to Aluminum Wheels – 15″
$75.00 -
Simple 110V Package
$125.00 – $275.00 -
12V Battery w/ 110V Charge Kit
$445.00 – $610.00 -
Add’l LED Interior Lights
$25.00 -
Aluminum Sidewall Vent
$75.00 -
Cabinet, 32″w Single Door with Clothes Rack
$425.00 -
Cabinet, 44″w with Clothes Rack
$500.00 -
LED Backup Lights
$120.00 -
LED Loading Lights
$90.00 -
RV Roof Vent Cover
$60.00 -
Stabilizer Jacks – 750# Rating
$100.00 -
Stabilizer Jacks – Drop Leg
$265.00 -
Finished Ceiling
$320.00 – $1,040.00
