Single Axle Cargo Trailers

the Superior Strength & Style of Our Single Axle Cargo Trailer.

Looking for a rugged and lightweight aluminum cargo trailer? These trailers are all built on all aluminum frames and paired with a galvanized Dexter Torflex axle with EZ Lube hubs. Our enclosed cargo trailers are available in many widths and lengths so if you don’t see what you want listed below please give us a call.

Like all our aluminum trailers these single axle cargo trailers are built right and ready to go to work. Screw-less aluminum painted exterior sides, LED trailer lights, side door with RV latch, quality roof vent, 3/8″ interior walls, multiple LED interior lights with switch, swivel tongue jack, galvanized wheels, and 15″ radials all standard features.







1
1
Images may show optional upgrades.

Swipe To See More Images

Let's Talk Trailers

ModelCRG 510CRG 610CRG 612CRG 80-12
Factory Direct Price
6'1" Max Int Ht
$6,395
$6,795
$7,295
$7,395
Interior Length9'11" + 20" V9'11" box + 3' V11'11" box + 3' V11'11" Box + 35" V
Interior Width57"69"69"77"
Interior Height5'6", 6'1", or 6'6" Options, Net Height Is Less
Overall Length13'7"15'1"17'1"17'5"
Overall Width82"94"94"102"
Overall HeightSee Link
Deck Height18"18"18"20"
Top of Ball / Ball Size17" / 2"
Curb Weight*950#1150#1225#1350#
GVWR2990#2990#2990#2990#
Note Other sizes available. Call for details.

ModelALL MODELS
FrameAll Aluminum Tubular - 2"x5" Main Frame
AxlesGalvanized Dexter Torflex w/ EZ Lube Hubs
BrakesOption
TiresST205/75R15 LRC Radial Tires
Wheels15" Galvanized Wheels w/ Chrome Center Cap & Acorn Lug Nuts
Exterior Skin.030 Painted Aluminum Sheets - Screwless
24" Stoneguard on V-Nose
Wall/Roof StructureAll Aluminum Tubular - 16" On Center
Roof SkinSeamless Mill Finish Aluminum
Flooring3/4" GP DryMax High Performance Floor
Exterior LightsLED Stop-Turn-Tail, LED Sidemarker, LED Clearance, LED Plate Light
Interior Lights2
Interior3/8" GP Drymax Iterior Walls
Tiedowns / Roof RacksOption
Trailer Doors32" x 68" Side Access Door w/ RV Lock
CHOICE: Rear Ramp Door w/ Spring Assist or Rear Cargo Door(s)
JackstandSwivel Jackstand w/ Wheel
Ramp Door HingesAluminum w/ Grease Fittings
VentilationCHOICE: Ventline Pop-Up Roof Vent (1) or Black Plastic Sidewall Vents (2)
12 V Power4 Way

Every PROLine trailer is available in multiple different solid colors at no additional charge for any one color. We also offer Blackout Trim, Two-Tone combinations, Two-Tone w/ ATP Accent, & Aluminum Stoneguard Sides.

enclosed motorcycle trailertrailer colorstrailer color
Single Axle Aluminum Trailers 1colorsSingle Axle Aluminum Trailers 2
Single Axle Aluminum Trailers 3Single Axle Aluminum Trailers 4Single Axle Aluminum Trailers 5
Single Axle Aluminum Trailers 6Single Axle Aluminum Trailers 7

Rugged Aluminum Frame

Our aluminum trailers are built to last, starting with rugged main tubes and fully welded joints. We know what types of roads our trailers are dragged over when they leave our facility and our trailers are ready for them.

Quality Trailer Parts

A strong frame is only as good as the components to support it. This is why we use only the best of parts on our aluminum trailers like galvanized Dexter torsion axles, high quality radial tires, LED lighting, and self-adjusting brakes.

2.5x Stronger Roof

Our roofs are built with rugged 1″×2″ aluminum tubes on 16″ centers. That means a roof nearly 2.5 times stronger than many other trailers on the market. We tend to get a lot of snow in New Hampshire, our trailers are ready for it.

Attention To Detail

Every trailer we build is checked and double checked before it leaves our shop. We want to make sure our trailers are looking their best with screws lining up, lines cut straight, doors installed tight, and every trim screw properly located.
